Mini Portable Concrete pump

  • Model:LMP7/35
  • Output:7.5m3/h
  • Pumping Pressure:35bar
  • Max. Aggregate Size:15mm
  • Cylinder diameter:Ø120mm
  • Overall Dimension:1950*700*1130mm

  • mini concrete pump
  • portable concrete pump
  • small portable concrete pump
  • Mini Portable Concrete Pump
Shotcrete Machine
Grouting Equipment
Industrial Peristaltic Pump
Plaster Machine
Soil Spraying Machine
hydraulic pump station
Foam Concrete Machine

TEL

86-371-63902781

skype:

shotcreter

Email

sales@leadcrete.com

FAX

86-371-63902781

ADDRESS

Xisihuan Ring-Road East, Tielu, Xiliu Lake sub-district, Zhongyuan District, Zhengzhou, Henan China

■Introduction

 Description:
LMP7/35 is a concrete & grout pump designed for masonry grouting and shotcrete applications. It
features up to 7.5 cubic meters per hour production output. This product is a new, multi-purpose,
multi-purpose industrial pump developed by absorbing advanced technology from abroad. Typical
applications include: masonry block filling, wall grouting, hoisting mortar for masonry wall construction;
 concrete sidewalk and patio slab pumping; low-volume shotcrete.

 Application:

Ø  Concrete/bridge repair

Ø  Machine base stabilization

Ø  Masonry block fill

Ø  Mining

Ø  Piling encasements

Ø  Pressure grouting

Ø  Refractory

Ø  Shotcrete

Ø  Slabjack/mudjack lifting

Ø  Soil stabilization

Ø  Void fill

 Features:

Ø  7.5 m3 per Hour

Ø  Production Rate

Ø  S tube valve

Ø  Self-Propelled

Ø  Equipped Wireless Remote

Ø  Electric Powered Version

■Product Details
mini portable concrete pump cemented carbide wear platering

mini portable concrete pump cemented carbide wear platering

concrete grout pump polyether material piston

concrete grout pump polyether material piston

mini concrete pump swing tube valve

mini concrete pump swing tube valve

mini masonry concrete pump air cooling system

mini masonry concrete pump air cooling system

portable concrete pump solid tyre

portable concrete pump solid tyre

small protable concrete pump automatic lubricating oil

small protable concrete pump automatic lubricating oil

■Technical Parameters

Technical Data:


Name Mini Masonry concrete pump
Model LMP7/35
Output 7.5m3/h
Pumping Pressure 35bar
Max. Aggregate Size 15mm
Cylinder diameter Ø120mm
Cylinder Stroke 360mm
Conveying Hose Inner Diameter Ø80mm
Main Motor Power 15Kw
Max. Vertical Conveying Distance 30m
Max. Horizontal Conveying Distance 90m
Overall Dimension 1950*700*1130mm
Weight 750kg
Note: the machine can be equipped with electric walking device according to customer demands.
